Forced-entry security, not a vehicle-impact rating. LPS 1175 addresses forced entry. No crash rating is stated for this product; do not infer one from its inclusion in the HVM range.

Request a Quote 877-572-4667

At a glance

Technical specification
Hinges	Heavy duty with needle roller bearings and thrust bearings
Finish	Pre-Treatment: Blast Cleaned SA2.5 – Primer: Interpon PZ790 (or equivalent) – Topcoat: Interpon D1036 PPC (or equivalent)
Colour	Standard RAL
Speed of Operation	approx. 10-12 seconds

01Specification

Technical specification
Hinges	Heavy duty with needle roller bearings and thrust bearings
Finish	Pre-Treatment: Blast Cleaned SA2.5 – Primer: Interpon PZ790 (or equivalent) – Topcoat: Interpon D1036 PPC (or equivalent)
Colour	Standard RAL
Speed of Operation	approx. 10-12 seconds
Manual Override	Manual opening and lock open in event of power failure
Power Failure	Fail secure
Control	Housed within 200mm x 400mm gate posts. No external cabinets.
Access	For access controls see LPCB Certificate.
Power	240V 16A supply
Safety	Conforms to DHF TS013:2021

02Model: EAG50010-A1

Technical specification
Certified to LPS1175 A1 (SR1)
Opening	Height 1.8m, max 5.0m.
Width	Single Leaf max 5.0m, Double Leaf – max 10.0m.
Infill	Vertical bar or 358 weld mesh

03Model: EAG50010-B3

Technical specification
Certified to LPS1175 B3 (SR2)
Opening	Height min 2.0m, max 5.0m.
Width	Single Leaf max 5.0m, Double Leaf – max 10.0m.
Infill	CHS Vertical bar, SHS vertical bars with 358 weld mesh, Super10 mesh.

04Model: EAG50010-B3

Technical specification
Certified to LPS1175 C5 (SR3)
Opening	Height min 2.4m, max 5.0m.
Width	Single Leaf max 5.0m, Double Leaf – max 10.0m.
Infill	SHS vertical bar, SHS vertical bar with 358 weld mesh, Super10 & ArmaWeave mesh.
