Truckstopper 10

PAS68

At a glance

Technical specification
Min. Planting depth	200mm
Height Above Ground	900mm
Security Rating	(BSI PAS68:2010) V/7500(N2)/64/90:2.8/7.2
Tested Core Dimensions	100MM W X 190MM L X 900MM H FROM FFL

01Product Overview

Truckstopper 10 is one of the only impact rated bollards available on the market today as a surface mounted option. This product is ideal for sites where there is a potential for foundations conflicting with underground utilities and services. This allows for installation at a fraction of the cost of traditional bollards.

Unlike traditional steel tube bollards, Binns truckstopper 10 utilizes our patented spring steel design, creating a durable, ultra slimline product that is ideal for blending into the public realm.

Truckstopper 10 is single tested, so does not need to be installed in an array. The system is designed to follow the contours of the ground so can manoeuvre around corners, bends, and can be installed on a incline.

02Truckstopper 10 Specification Details

Technical specification
Min. Shroud measurements	1500mm l x 460mm w x 930mm h as standard
Min. Planting depth	200mm
Height Above Ground	900mm
Security Rating	(BSI PAS68:2010) V/7500(N2)/64/90:2.8/7.2
Tested Core Dimensions	100MM W X 190MM L X 900MM H FROM FFL
Minimum Array	ONE
Shroud Material	316 STAINLESS STEEL WITH LINEN FINISH AS STANDARD
Ral Options	ANY STANDARD RAL COLOUR
Foundation Depth	200MM

03Finishes

Oval 316 stainless steel mitre top cover with up to 2 hi-vis bands as standard. Alternative finishes available. Please contact your sales representative for more details.
