PAS68 Automatic Bollards EAG06000 Range

At a glance

Technical specification
Impact rated as a single bollard. Zero penetration supplied with integral re-bar.
Crash rated to 7.5T (N2) @30mph (48kph)
Height	1000mm above FFL
Foundation	1.2m x 1.2m x 1.7m

01Model: EAG060-30A

Technical specification
Impact rated as a single bollard. Zero penetration supplied with integral re-bar.
Crash rated to 7.5T (N2) @30mph (48kph)
PAS68	2010 V7500(n2)48/90:0/0
Diameter	219mm
Height	1000mm above FFL
Finish	Galvanised and powder coated, Optional stainless steel
Foundation	1.2m x 1.2m x 1.7m
Raise Speed	6-8 seconds standard, 1-2 seconds with optional EFO
Power Supply	Three phase

Technical specification
The world’s shallowest foundation telescopic rising bollard tested with the 7.5T (N2) 48kph (30mph). This has a foundation depth of just 500mm. Supplied with integral re-bar.
Crash rated to 7.5T (N2) @30mph (48kph)
PAS68	2010 V7500(n2)48/90:0/0
Impact rated as a single bollard.
Height	900mm above FFL
Finish	Tufftride and hard top paint.
Foundation	1.7m x 1.7m x 0.5m
Raise Speed	8-10 seconds standard, 2-4 seconds with optional EFO
Power Supply	Three phase

Technical specification
A high impact rated bollard tested with the 7.5T (N3) vehicle at 50mph (80kph). Supplied with integral re-bar.
Crash rated to 7.5T (N3) @50mph (80kph)
PAS68	2010 V7500(N3)80/90:5.9/7.0
Impact rated as a single bollard.
Diameter	323mm
Height	1200mm above FFL
Finish	Galvanised and power coated, optional stainless steel.
Foundation	1.2m x 1.2m x 2.0m
Raise Speed	6-8 seconds standard, 1-2 seconds with optional EFO
Power Supply	Three phase
